PRODUCT FAMILY SPECIFICATIONS CONSTRUCTION - Die-cast housing with hidden vertical heat fins that are optimal for heat dissipation while keeping a clean smooth outer surface - Corrosion resistant, die-cast aluminum housing with powder coat paint - Separate optical and electrical compartment for improved thermal management and optimum component operation - TGIC thermoset polyester powder paint applied at nominal 2.5 mil thicknessOPTICS - Entire optical aperture illuminates to create a larger luminous surface area resulting in a low glare appearance without sacrificing optical performance - Premium engineered individual acrylic lenses deliver IES Type 2, 3, 4W and 5QW distributions - Lens distributions are field rotatable (in 90- increments) or exchangeable for job site fine-tuning - 3000K, 4000K, or 5000K (70 CRI) CCT - 80, 160, or 320 midpower LEDs - 3000K, 4000K or 5000K (70 CRI) CCT - Zero uplight at 0 s of tilt - Field rotatable opticsINSTALLATION - Tool-less entry to wiring/ compartment optional - mounting block works with #2 drill pattern - Fixture ships with slotted mounting block to accommodate wide range of drill patterns for easy retrofit opportunities - Mast arm fitter accessory or option available for 2-3/8' OD brackets with vertical tilt of +3 , 0 or -3 ELECTRICAL - 120-277 VAC or 347-480 VAC input voltage, 50/60 Hz - Ambient operating temperature -40 s C to 40 s C - s have greater than 90% power factor and less than 20% THD - LED s have output power over-voltage, over-current protection and short circuit protection with auto recovery - Field replaceable surge protection device provides 20KA and 10KV protection meeting ANSI/IEEE C62.41.2 Category C High and Surge Location Category C3; Automatically takes fixture off-line for protection when device is consumedCONTROLS - Photo control, occupancy sensor and wireless available for complete on/off and dimming control - 7-pin ANSI C136.41-2013 photocontrol receptacle option available for twist lock photocontrols or wireless control modules (control accessories sold separately) - Dimming s are standard and dimming leads are extended out of the luminaire unless control options require connection to the dimming leads. Must specify if wiring leads are to be greater than the 6 - SiteSync wireless control system is available via 7-pin (See ordering information - NX Distributed Intelligence available with in fixture wireless control module, features dimming and occupancy sensor wiSCAPE available with in fixture wireless control module, features dimming and occupancy sensor via 7-pin - Please consult brand or sales representative when combining control and electrical options as some combinations may not operate as anticipated depending on your application CERTIFICATIONS - Listed to UL1598 and CSA C22.2#250.0-24 for wet locations and 40 s C ambient temperatures - DLC (DesignLights Consortium Qualified),with some Premium Qualified configurations.Please refer to the DLC website for specificproduct qualifications at - 1.5G rated for ANSI C136.31 high vibration applications - IP65 optical assembly - Meets IDA recommendations using 3K CCT configuration at 0 s of tilt - This product qualifies as a :designated country construction material: per FAR 52.225-11 Buy American-Construction Materials under Trade Agreements effective 04/23/2020. See Buy American SolutionsWARRANTY - 5 Year warranty
